One for the Road, Two for the Trees

Although I was happy enough with the roadway on 'odsock Corner I felt that it fell short of representing the rough surface of a obscure countryside trackway. The area that I was happiest with was the second crossing where I had a good basis for the areas worn away by traffic and time. I was convinced that I could get a better texture and colour...

Another mix of paint, PVA, tile grout powder and fine ballast was created, this time with more brown paint to warm the shade. This was laid over the original surface but not consistently, creating variation in tone and level. Whilst the mix was wet yet more fine ballast was sieved over and tamped into place to create further texture.

I then let it dry overnight before the temptation to tinker set in. The following day further sanding of the surface took place, then some cunning setting of the resultant debris using matt medium. Another overnight to dry and weathering powders were used to add further colour variation to the various areas to represent those places where the dampness always seems to linger longer.

With plenty of mixture left over and knowing it would not keep, the area in front of the office building and around to the disconnected siding were treated, in front of the office I added both ballast and ground foam to the wet mixture to represent a rudimentary gravel path in the earth. As with the surplus of the first road surface mix, I also took the opportunity to coat the areas of ground formed from paper laid over polystyrene. Once everything was dry the grunged-up area of track had some shading added using weathering powders.

I do like the way the siding squeezes between the office and the tree... talking of trees, you may spot in the photos above that something curious might be going on... I had established early in the design process that I would use a Hornby Skale Scenics tree that I re-foliaged a couple of years ago, but I had a feeling that I may need a little more. Back in May I purchased some fir trees by 'Model Scene' (not the Peco brand) from CM3 Models with no real purpose in mind (other than joking about turning this layout into another Christmas scene!) but with the scenery now well under way I decided to try one in the gap next to the other tree.

It has no trunk to speak of below the branches so is actually floating in fresh air at the moment. The flash of red through the leaves is a clip holding another idea in place. This twig was pruned from a bush in the garden last year along with a couple of others with their use as tree armatures in mind. A tree in this location was indicated on the mock-up but it is close to the edge of the board so will require some care and thought to create something that will not clash with the covering box.

Of course all of these trees are actually under-scale but at least they have enough height to not look too wrong in proportion to the small space of the layout. With plenty of smaller shrubs and bushes around I think the overall result will be effective.

Colin

Beyond the Kato 11-109 - the 11-108!

Back in February I completed number 6, a Simplex from FK3D styled on the Abbey Light Railway's 'Druid'. This ran on a Kato 11-109 as intended by the maker, although I had revealed a little more of it by removing the false 'skirt' under the underframe to make the end result more realistic. However, I always thought that it looked a little too 'perched' on the chassis, in particular too much clearance under the re-railing bars was a bit off-putting.

The inspiration for what follows was actually my yet to be built FK3D Lister locomotive, which takes advantage of a feature of the new-generation Kato chassis being built around a 'core' of weights holding the motor, flywheel, drivetrain etc to the point that the upper cover really only stops things falling out of place. I had also discovered the version of the Kato chassis (11-108) that had very little detail and was in fact noticeably narrower than the fake locomotive sideframes of the 11-109. My initial thoughts to somehow use a chassis without a cover and wondering how to fix it in place, turned to using a further-reduced 11-108 to lose 1mm in ride height.

The starting point, number 6 on a 11-109, with a frame height of 14.5mm and the 11-109 sideframes filling the space underneath.

The alterations required the the 11-108 chassis (stock Kato image used). The aim was the leave a raised area in the centre to match the opening in the body of the 3D print. In particular I will draw your attention to the cut at the right hand end of the top - do not cut to the right of the raised area as this will remove the clip that stops the motor moving backwards, I started this but soon realised my error! Cut along the opening about 1.5mm in from the edge instead and then file down the area to the right. All cuts were made with the top cover removed from the motorising unit.

The resultant conversion is seen with the original 11-109, we can see how much narrower it is and how the end platforms are lower than the 11-109 frame. The areas over the axleboxes were at about the same height as the 11-109 frame but I have chamfered them away to fit into the cut-away area under the body. I have painted the axleboxes matt black to better hide them and switched the baseplates over to give the new chassis the sprayed matt black one from the original chassis.

In order to secure the new chassis in place I have used two screws which pass through the endplates into holes drilled in the underside of the body, centre at the rear and to one side at the front. As the motor protrudes out of the top of the cut-down chassis I had to remove an area under the bonnet of the print and reposition the weight that counterbalances the whitemetal driver figure. This view shows the slightly angled areas that will form the main interface between the new chassis and the body, inboard of the strips that sat on the 11-109.

The end result is a 13.5mm measurement to the top of the frame, bringing the rerailing bars closer to the rails and looking a lot less perched with the bonus of fresh air between the axleboxes and the ends of the loco.

So, was it worth it? I think so! Now you might be wondering why I didn't just cut away the old frame and carry out the same modifications, well I find the Kato plastic a little awkward to work and the less I had to remove the better, especially along the length. I also have memories of taking too much away from a 11-103 in the past and actually rendering it useless... but at least I have a spare motor for my older locos...

Colin

Carry on Again...

A midweek "extra", things must be moving along!

With the basic box assembled I added a few features to allow 'odsock corner to be securely stored within or displayed on top. A peculiarity of this build is that usually I would drill holes in the front and rear of the box as these are usually the longest elevations, but this one is square, and there is also the issue of the front of the layout being drop-framed and having less space underneath...

As well as drilling the holes for the bolts, on top of the box I added two plywood triangles which suffice to engage in the front corners of the baseboard to secure it when displayed.

Although the bolt holes in the box are in the front and rear... the corresponding holes in the layout are in the sides of the board and a 90 degree turn is required on un-boxing, hardly arduous! Under the board captive bolts are held in place with small blocks of timber, drilled through and then opened out to hold the bolt. These were clamped and bolted into place whilst the PVA glue dried, with WD40 on the bolt threads to try and avoid any unwanted fixing.

After a mask up of the edges of the hardboard panels with low-tac decorators tape all the timberwork then had two coats of yacht varnish applied. Disaster then struck when the low-tac tape lifted the surface of the hardboard in places making a bit of a mess. Varnish also ended up where it wasn't really meant to leaving me to say this isn't my best work... The surface of the hardboard had some wax furniture polish applied which hides the worst of the damaged surface.

The layout board also had a coat of yacht varnish on the underside to protect the woodwork and then a couple of coats of grey primer on the outside edges, another coat of this may be the final colour in due course, applied after scenic work is completed. It is all looking very grey at this stage, the other day someone mentioned that they actually thought it was going to be a winter scene, but another season will soon roll around.

More soon...

Colin

Carry on Clamping

The storage box for 'odsock Corner is now complete, it has been something of a saga for what should be a simple job! Firstly, I didn't have the hardboard and timber strip in stock as I had used most of the supply last year when I enclosed part of my new shelving in the workshop (which of course I have done nothing with...), so a trip to B&Q ensued and a shock at the price of these supplies (my old hardboard was free from an old wardrobe!). The new timber strip, despite being the same size as the old stuff, was actually slightly bigger too but I've ignored that.

After careful measurement of the baseboard and material thicknesses, I calculated the sizes of the hardboard panels (with a +1mm allowance) and cut them accordingly. The timber, 25x11mm section (which B&Q retail as 25x10.5mm) was cut, again slightly over-length, and panels then assembled one-by-one, to get as many clamps on each as possible. Allowing for drying time this took place over a couple of days, after which I sanded all the edges of the hardboard back to the edges of the timber to allow for neat and square corner joins.

From my home made kit of parts I could then assemble the box. Being a square layout my sides are not equal lengths, the two shorter ones sitting inside the two longer ones to make the square. I paired up one of each on a flat surface, glued and clamped them together, checking for squareness and then repeated for the second pair. My 18" clamps came into their own with this along the top edges (at the bottom) supported by the smaller clamps along the corners.

The two pairs of sides were then brought together, again on a flat surface, into one assembly. Again, plenty of clamping!

The final piece of hardboard to add was the top, this was slightly oversize and would be adjusted at a later stage. The timber lengths under the clamps are to spread the force along the edges of the board and keep pressure along the edge as the glue dries.

Once set the edges of the top were sanded smooth and then the saga took a new turn. The vertical timber sections protruded slightly below the hardboard sides and I decided to sand these down. My power sander had other ideas and when I wasn't looking took a chunk out of the hardboard in one corner. Words were said, tea was brewed and I went off and cut the grass... on my return I had cooked up an audacious plan to remove a strip from the entire base of the box, hardboard and timber. This was carefully measured out and the timber corners cut first with a fine saw, and the hardboard with a combination of Stanley knife and saw. It worked, and (gently) sanded to finish the result was actually better than it would have been originally.

By co-incidence the height of the box was now actually identical to that of my 009 layout 'The Old Quarry Line's box, which it probably should have been all along! However, the saga (or given this post's title, the farce) would continue to throw a few curveballs at the subsequent stages...

Colin

O9 Archeology

The 7mm Narrow Gauge Association has recently restarted it's second-hand sales service, as mail-order, members-only service with items listed and illustrated on a dedicated website page. Mention in 'Narrow News' that a quantity of O9 items were selling well led me to log in and take a look. Amongst the interesting items was an Owen Ryder R&ER coach kit, unopened... emails were exchanged. Paypal paid and the Royal Mail delivered.

It really is unopened, look at that tape! This really is a time capsule from one of the earliest manufacturers of O9 models. The range was later taken on by the late Howard Martin at Avalon Line from whom I bought a version of this kit a good few years ago. It's build was described in Building the Avalon Line 'Ratty' Coach Kit.

So, did I keep it wrapped up for posterity or break it open and build it? I gave in to temptation, opening the tape and removing everything from the bag, it was a very tight fit! Inside all the parts are still carefully wrapped up in tissue paper, secured with more tape. My temptation was only partial as I haven't opened that, yet...

Colin

The Road to Nowhere

With the rockfaces on 'odsock Corner coloured to an initial satisfactory finish my attention turned to the road surface. My aim is to achieve both of these finishes prior to general ground surfacing, in order to allow the latter to overlap in a realistic fashion. The basis of the roadway had been laid some time ago in the form of mounting card and treated with button polish to harden the surface. I had intended to then follow a similar principle to that used on 'Shifting Sands', only to find, much to my surprise, that the Green Scene product I had used 18 years ago, had dried up...

The first step I took was to weather the planking on the first crossing, using various washes of acrylic followed by dry brushing in weathered wood shades. The centre planks are not yet stuck in place and are out of line in the picture.

The roadway itself is a concoction of grey tester pot paint (with a spot of brown), PVA glue, grey tile grout powder, very fine sand and the finest material sieved from my ballast mix. This was applied liberally over the roadway, adding in extra loose ballast material on the surface where required, in particular around the second crossing and to the right hand side in the areas that I had previously excavated in the road surface. The surface was stippled whilst wet to add some extra texture to the surface.

Once left overnight to dry I revisited the surface and despite my texturing I actually went over it with 400 grit wet and dry to smooth it a little. This had the added bonus of removing the mixture from some of the ballast in the mix and adding some further variation of colour. I then spent some time with watercolour paints and weathering powders to further vary the surface colours and add impressions of tyre tracks and wear.

Despite looking complete, this is really a base for further work once the surrounding scenery is in place, I can foresee adding some further "loose" material and some cracking to really get the impression of a broken-up surface.

More soon.

Colin

Saturday Snapshot III - Rocks

As anticipated I have applied some colouring to the rocks around the pizza layout using various shades of acrylic paints in the beige/grey spectrum. Dry-brushing has brought the rocks to natural shades including green at the base of the rocks to represent a damper area and staining from vegetation growth.

I've also added water stains running down the faces of the rocks, maybe a bit too obvious at the moment... There will be another round of dry-brushing in due course to add a more sandy/yellow tint and as scenic work progresses there will be moss/lichen effects to add using ground foam etc.

Colin
